Panasonic AV-HS410

Aquilon RS1 is a mission-critical 4K / 8K multi-screen presentation system and video wall processor with 16 inputs and 8 outputs that provides an uncompromising presentation experience for high-end presentations and first-class system integration. Aquilon RS1 combines industrial-grade reliability, andThe Panasonic AV-HS410 is an HD / SD switchable 1ME mixer that can compete with many high-end mixers with its wide range of inputs and outputs, many attractive effects and system expandability. In the standard configuration it has 9 inputs and can be expanded to a maximum capacity of 13 inputs if expansion boards are installed. The mixer offers versatile effects, such as transitions with digital video effects and Primatte® chromakeying applications. The 7-inch (178 mm) color LCD monitor makes operation easy with a clear settings screen, memory preview, enhanced MultiViewer functions and a button layout that makes live broadcasting much easier.

The Panasonic AV- HS410 multi-format image mixer comes standard with 9 inputs (8x HD/SD SDI + 1x DVI-D) and can be optionally expanded to a maximum of 13 inputs. With its simple user interface, the AV-HS410 is safe to operate and meets the requirements in the studio as well as in live production.

In the standard configuration, the new model has 8 HD/SD SDI inputs and can be expanded by a further 4 inputs (optional). One DVI - D input, as well as 5 SD/ HD SDI outputs, expandable by another 4 (optional) Via the built-in 7 inch LCD monitor, the inputs / outputs can be displayed individually as well as in the multi-view function. A waveform monitor as well as a vectorscope display can be faded in.

Exceptional ease of use, versatile 4K digital connectivity, unsurpassed real-time 10/12-bit 4: 4: 4 video processing performance, superior image quality and pure 4K60p quality at each input and output with extremely low latency.

16 seamless inputs

16 seamless 4K60p inputs via 4 pre-installed input connection cards:

8 HDMI 2.0 (18 Gbit / s bandwidth for up to 4K60p 8-bit 4: 4: 4 or up to 4K60p 12-bit 4: 2: 2 or up to 4K30p 12-bit 4: 4: 4)

4x DisplayPort 1.2 (21.6 Gbit / s bandwidth for up to 4K60p 10-bit 4: 4: 4 or up to 4K60p 12-bit 4: 2: 2)

4x 12G-SDI (up to 4K60p 10-bit 4:2:2) - also compatible with 3G-SDI and 6G-SDI

All input connection cards can be replaced in the field to allow a variety of connectivity arrangements

Full set of input connection cards sold separately (DP 1.2, 12G-SDI, HDMI 2.0)

Supports 4K60p inputs as single, dual or quad connectors (end 2019)

Supports input formats such as 8192 × 1080 @ 60p or 1080 × 8192 @ 60p (also known as "8k x 1k") on a single port

Connection status LEDs for easy troubleshooting

8 active outputs

8 active 4K60p outputs via 2 pre-installed output connection cards:

8x HDMI 2.0 (18 Gbit / s bandwidth for up to 4K60p 8-Bit 4: 4: 4 or up to 4K60p 12-Bit 4: 2: 2 or up to 4K30p 12-Bit 4: 4: 4)

All output connection cards can be replaced in the field to allow a variety of connectivity arrangements

Full set of output connection cards sold separately (DP 1.2, 12G-SDI, HDMI 2.0)

Supports 4K60p output in single, dual, or quad (end 2019)

Supports custom output formats such as 8192 × 1080 @ 60p or 1080 × 8192 @ 60p (also known as "8k x 1k") on a single port

Connection status LEDs for easy troubleshooting

10- and 12-bit processing with extremely low latency

Based on the exclusive 5th generation scaling engine from Analog Way

Extremely low latency, only 1 frame with correct configuration

40 megapixel throughput at 10 bit 4: 4: 4 at 60 Hz in the program without limiting the preview or multiviewer

HDR compliant with HDR10 and HLG (end of 2019)

Advanced motion compensation deinterlacing

BT.601; BT.709; BT.2020; BT.2100 Colour spaces

Compatible with HDCP 1.4 Compatible with HDCP 2.2 (end 2019)

Up to 4x 4K mixing layers

Supports layer mixing (true seamless transitions) and layer splitting (cut transitions)

Up to 4x 4K or 8x Dual / 2K mixing planes (8x 4K6 or 16x Dual / 2K6 split planes) depending on screen settings

The layer source can be a live input, a still image (or a screen PGM for split layers).

Each output has an unscaled background mixer that supports seamless transitions

The background source can be a still image or a live source
